Parkside Plasma Cutter PPS 40 LIDL accessories test manual

Parkside Plasma Cuter PPS 40 LIDL is intended for compressed-air plasma cutting of all electrically conductive metals. For precise and clean cuts through material up to 12mm thick .Suitable for cutting sheet steel, stainless steel, aluminium, copper and iron. Adjustable cutting current (15 to 40A)

Video : https://www.youtube.com/watch?v=N4Wh4_NG7VE

Lien de la vidéo : https://www.youtube.com/watch?v=j4tv0KvTNzw

Lien de la vidéo : https://youtu.be/8FNDP2I_2So

Parkside Plasma Cutter PPS 40 LIDL- Technical data

IAN : 307722

Model : PARKSIDE PPS 40 A1

Output: 15-40 A

Input: 230 V~ 50 Hz

Weight: approx. 5.2 kg

Dimensions : 341 × 113 x 237 mm

Insulation class: H

Duty Cycle:

• 35 % at 40 A (25 °C)
• 20 % at 40 A (40 °C)

‘Real’ cutting capacity: 0.1 mm – 12 mm (depending on the material)

• Copper:1-4 mm
• Stainless steel: 1-8 mm
• Aluminium:1-8 mm
• Iron: 1-10 mm
• Steel: 1-12 mm

Working pressure: 4-4.5 bar (4 bar preset)

Durable, powerful and compact

Electronically controlled, quiet and even plasma jet

For precise and clean cuts through material up to 12mm thick

Suitable for cutting sheet steel, stainless steel, aluminium, copper and iron

Adjustable cutting current (15 to 40A)

High-quality 2.5m cutting cable with replaceable torch attachments

Earthing cable (2m) with strong clamp

2m compressed air hose with quick coupling

Rear compressed air connection including pressure reducer

Overload protection due to the thermal monitor with indicator light

Housing made from painted sheet steel with an ergonomic carrying handle

Warranty : 3 year

Price : - £



Packtage content

1 plasma cutter PARKSIDE PPS 40 A1 LIDL

1 ground cable with terminal

1 cutting cable incl. cutting torch

1 compressed air hose with Quick-Connect

2 hose clamps

2 nozzles

3 electrodes (1 pre-assembled)

3 burner sleeves (1 pre-assembled)

1 set of operating instructions
